Product Specifications

Model	LM760
Voltage	110-240V,50/60Hz;
Bulb Model	40W RGBW 4 in LED,19pcs;
Power	850W
IP Level	IP 20;
Size	17.5KG;
Function	wash
Carton Size	535x440x585mm;

Product Description
Accessories

19*40W LED Wash Series – with a total power of 760W and high light output of 14205lm, featuring a beam angle adjustable from 4° to 36°. It comes with a 4-in-1 RGBW or RGBWL light source, supporting DMX512 and RDM dual protocols.
It offers individually control and delivers uniform light spots.
Applicable for: Concert lights, theater lights, church lights, sports event lighting, outdoor event lighting, wedding venue lighting, banquet hall lighting.

Channels mode:20CH/30CH/77CH:
Light source:40W RGBW 4in1 LED,19 pcs;
Life time: 20000 hours;
Light output Luminous:11000lm:
10milluminance(min/max):13300 lux/1.3m,450 lux/10m;
Power:AC110-240V~.50/60HZ:
Total power:760W:
Display:2.8 inch LCD display,can reverse 180°;
Beam angel:7°-53°:
Dimmer:0-100% mechanical dimming;Controlmode:DMX512.RDM,self-propelledmode;Positioning technology: Adopt the latest generation of positioning technology- magnetic encoder for precise positioning.which is more than 20 times more accurate than Hall positioning, and is not disturbed by oily smoke, dust, and light.USB: Support to pull out the address code when the power is off, and can be used as an externalinterface for software upgrades;Support the RDM protocol interface, and remotely intelligently dial the address code through the console;

Pan:540°;8 Bit/16Bit; Tilt:270°;8 Bit/16Bit;
IP Rate:lp20;
Datain/out:3-pin and 5-pin XLR;
Product size:415X305X550 mm;
Flycaes:800x510x765 mm(include Wheel);
Catron box:615x430x500 mm;
N.W.: 17 kg; G.W.: 20 kg(catron box).
